ASROCK Z87 Pro3

Reliable and powerful motherboard with the new socket 1150 . Equipment board contains all the modern technology - is present PCI Express 3.0 port for video cards, 6 SATA3 connectors support USB 3.0, DDR3 memory (up to 2800 + MHz frequency) and UEFI BIOS. For maximum reliability, the board is equipped exclusively Solid Capacitors and a digital power supply Digi Power .

Brand new Intel Z87 chipset adds support Core processors fourth generation Intel Haswell for socket 1150th This is the highest model 8 series and the successor to the popular Z77. Z87 Chipset supports overclocking processors, memory and video cards. The novelty is Intel Remote Wake That will, in conjunction with Microsoft Windows 8 to remotely control your computer from any other computer, smartphone or tablet.

Asrock to their plates adds a sophisticated software package. A-Tuning is a multifunctional program with the new environment and functions including, for example, OC Tweaker etc. And that's not all - using a unique function XFast 555 can reach up to five-fold acceleration of RAM, LAN and USB.

Specifications:

Supported Processors:
Model: Intel Haswell
Socket: LGA 1150

Chipset
Intel Z87

Memory:
Type: DDR3
Slot: 4x DIMM
Frequency: 1066/1333/1600/1866 (OC)/2133 (OC)/2400 (OC)/2800 + (OC) MHz
Connection mode: Dual-channel
Max. Capacity: 32 GB
Support for Intel XMP (Extreme Memory Profile) 1.3/1.2

Expansion Slots:
1x PCI Express 3.0 x16
3 x PCI Express 2.0 x1
2x PCI

Video:
According processor fitted
Max. shared memory: 1792 megabytes

Audio:
Realtek ALC892
7.1 HD

LAN:
Intel ® I217V
10/100/1000 Mbit/s

Internal interface:
6x SATA III (6 Gbit/s RAID 0/1/5/10)
1x IR
1x COM
1x S/PDIF
2x USB 2.0
1x USB 3.0

Power:
1x 24-pin ATX connector
1 8-pin 12V connector

External interfaces:
1x PS/2 (keyboard)
1x D-sub
1x DVI-D
1x HDMI
2x USB 2.0
4x USB 3.0
1x RJ-45 (LAN)
7x audio jack

Format:
ATX

Dimensions:
30.5 x 19.3 cm

Included accessories:
CD with drivers and software
I/O cover
2x SATA data cable
